Camden CM-331/42R-SGLR Surewave TCHLSS Switch, WC, WTO
The Camden CM-331/42R-SGLR touchless switches provide 'state of the art' door activation and control while eliminating the spread of germs.
Ideal for activation and control, where door status indication is required. This eliminates the need for a separate door control relay.
CM-331/42R-SGLR Application: Wired Touchless Switch w/ Built-In Door Control / 1 Relay / 6 Round Faceplate / 'SGLR' ling ring option / Hand Icon / Wave to Open text / Wheelchair Symbol.
Features and Benefits:
- Extended Range up to 6ft.
- Adjustable time delay 1 - 30 seconds.
- (4) selectable operating modes.
- Inputs for REX and door contact.
- Standard Operating Range - 1 - 28.
Specification Data:
- No. Of Sensors: 2.
- Operating Voltage: 12-24 Volts, AC/DC +- 10%.
- Current Draw: 40mA.
- Standard Operating Range: 1 - 28 (25.4MM - 711.2M).
- Auto Operation Range: 6 to 72 (152MM - 1820MM).
- Operating Modes (Motion Sensing Modes): MOMENTARY / MOMENTARY WITH ALARM / MAINTAINED (LATCHING) / AUTO RANGE.
- Relay Operating Modes: Single Event / Toggle.
- Relay Output: (1) FORM 'C' (SPDT).
- Relay Contact Rating: 3 AMPS @ 30 VDC.
- Output Type: Fail Safe or Fail Secure.
- Inputs: 'Request to Exit' External (Door Contact) Input.
- Current Draw: 8mA MAX.
Special Orders: For pricing on any Camden Door Controls Touchless Switches not on this page please contact Taylor via e-mail (sales@taylorsecurity.com) or call +1 (800) 676-7670.
