RCI 9322 Keypads & Readers

RCI 9322 Keypads & Readers

The 9322/9323 easy read prox micro readers are single door standalone access control solutions for flush mount applications. The RCI 9322 is a self-contained unit with a standalone reader, whereas the RCI 9323 is two separate components with a reader and controller. The readers are designed for subtly – the reader measures only 1-3/16"W x 1-7/8"H x 5/16"D and is flush mounted with black or white snap-on covers that can blend with any décor.

Technical Details
Dimensions: 1-3/16"W x 1-7/8"H x 5/16"D (29.5mm x 48mm x 8.5mm)

9322 Reader + Stand Alone
One Self-Contained Unit

9323 Reader + Controller
Two Separate Components

Accessories

• 932-10CP - Encoded card starter pack, 10 pack, includes wallet and programming cards
• 932-10KP - Encoded fob starter pack, 10 pack, includes wallet and programming cards

Accepts Keyfobs or Proximity Cards

9322 (Reader, 12VDC), 9323 (Reader/Controller Kit), or 9323MP (Reader Only).

• Easy to install
• Supports up to 10,000 users
• Aesthetically pleasing flush mount design
• Access validation – Silent (9322 only)/Audible
• Deny access without retrieving user’s card or fob
• No separate programmer required
• Input trigger for request-to exit or other open circuit contact
• Includes black & white snap-on covers
• Proximity cards and fobs are available in packs of 10 (sold separately)
