Precision PS161-6 Power Supply

SKU # PH/PS161-6

The PS161-6 Output Power Distribution Board is part of Precision Hardware

  • Voltage: 120V AC, 60HZ
  • Current: 3.5A AC
  • Input fuse ratings: 5A/250V
  • AC input is protected via an automatic reset circuit breaker
  • Battery fuse ratings: 7.5A/32V Output
  • Voltage: 12 or 24V
  • Total output: 6 amps
  • Power limit/output: 2 amps/per channel
  • Outputs: 8 (For Delayed Egress applications: use only 4)
  • Ripple voltage: 910mV (Filtered and regulated outputs)
  • Protection: Thermal and short circuit protection with auto

Delivery: The Precision PS161-6 Power Supply is factory-ordered, please allow 8-10 business days' lead time.

US$732.00

Taylor Security ID #: 8003684

Description:

Description:

Precision PS161-6 Power Supply

The PS161-6 Power Supply is designed as a power source for a variety of applications including Electric Locking, Exit Alarm and Delayed Egress Exit Devices. The Power Supply is a 120V input with a 12 or 24V output rated at 6A. It can control up to 4 delayed egress exit devices. Note: Adding additional loads to the PS161-6 Power Supply (i.e., Card Readers, Horns, etc.) may reduce the quantity of Delay Egress Exit Devices controlled by the power supply.

Special Orders: For pricing on any Precision Hardware Exit Devices not on this page please contact Taylor via e-mail (sales@taylorsecurity.com) or call 1-800-676-7670.

Features:

Features:

The PS161-6 Output Power Distribution Board is part of Precision Hardware

  • Voltage: 120V AC, 60HZ
  • Current: 3.5A AC
  • Input fuse ratings: 5A/250V
  • AC input is protected via an automatic reset circuit breaker
  • Battery fuse ratings: 7.5A/32V Output
  • Voltage: 12 or 24V
  • Total output: 6 amps
  • Power limit/output: 2 amps/per channel
  • Outputs: 8 (For Delayed Egress applications: use only 4)
  • Ripple voltage: 910mV (Filtered and regulated outputs)
  • Protection: Thermal and short circuit protection with auto

Delivery: The Precision PS161-6 Power Supply is factory-ordered, please allow 8-10 business days' lead time.
