Omnia Prodigy "912TD" Style Lever (Traditional Rose)

Omnia Prodigy "912TD" Style Lever (Traditional Rose)

Omnia 912TD, Sleek Lever with Traditional Rose
The beauty of the round rose and simple lever are sure to be eye-catching on any door. A true classic, the Sleek Lever With Stepped Round Rose is the perfect addition to traditional as well as contemporary homes. The stepped round rose adds a point of interest to an otherwise simple lever. Made by Omnia Industries, the 912TD Leverset is available in single dummy, double dummy, passage, and privacy functions. Both the single dummy and the double dummy functions feature concealed surface mounting for easy installation. The passage and privacy functions are available for either 2-3/8" or 2-3/4" backsets and the two functions are packaged for both 1-3/8" or 1-3/4" thick doors.

Features of the Sleek Leverset:
Concealed screw mounting.
Full lip strike comes standard.
28° rotation to retract latch.
Covers 2-1/8" bore hole.

Specifications of the Omnia 912TD Sleek Lever With Round Rose:
Lever Length: 5-1/4"
Lever Projection: 3"
Rose Diameter: 2-5/8"
Backset: Optional 2-3/8" or 2-3/4"
Door Thickness: 1-3/8" or 1-3/4"
When Selecting Function:

Single Dummy: A stationary lever for use as a pull or to match trim on one side of door. Includes 1 lever, 1 rose, and mounting screws.
Passage (hall or closet): For doors that don't need locking. Latch operates from either side of door. Complete set - 2 levers, 2 roses, 2 sub-roses, tubular latch, strike plate, spindle, and mounting screws.
Privacy (bedroom or bathroom): For doors that could need locking. Latch operates from either side. Push button on interior rose engages privacy; emergency release hole is on exterior rose. Turning inside lever will release privacy and retract latchbolt. Complete set - 2 levers, 2 roses, 2 sub-roses, privacy button, tubular latch, strike plate, spindle, and mounting screws.
Note: Single Dummy is Handed. All other functions are non-handed.

The "912TD" Lever is part of the Omnia Prodigy Series

"All Omnia Levers comes standard with 2-3/8" Backset (Latch), No. 014 "Full Lip" Strike, and are available for 1-3/8" & 1-3/4" Thick Doors"

Single Dummy Function: Single dummy function door hardware utilize this single dummy handle to create a uniform look throughout your home in the areas that do not require mechanical systems. Dummy door hardware is surface mounted with no locking mechanism and are used primarily for the inactive door in a double door installation serving as a pull.

Features:
Constructed of high quality brass for lasting durability
Installs easily with all necessary mounting hardware included
ADA compliant
Features concealed screws for a streamlined look

Specifications:
Handing: Left, Right
Handle Length: 5-1/4"
Handle Projection: 3"
Product Weight: 1-3/16 lbs
