Omnia 227S, Modern Door Lever Latchset
The transitional design of this modern door lever has a very contemporary style. The squareness of the rose is enhanced by the sleekness of the 277S Lever. It is available in polished chrome, satin chrome, satin nickel, and oil-rubbed bronze finishes as either a passage, privacy, or dummy function. Easy to install, this leverset made by Omnia will fit 1-3/8 inch, 1-3/4 inch or 2 inch door thicknesses with 2-3/8 inch or 2-3/4 inch backsets.
Features of the Contemporary Door Lever Latchset with Square Rose:
Solid brass construction.
Fits most standard door cut outs.
ADA Compliant
Specifications for the Omnia 227S Modern Door Lever:
Material: Solid Brass
Lever Length: 5-1/2"
Lever Projection: 2-3/8"
Rose Length: 2-9/16" square
Door Thickness: 1-3/8", 1-3/4", or 2"
Backset: either 2-3/8" or 2-3/4"
28 degrees rotation to retract latch.
Fits standard 2-1/8" inch door bore.
Concealed screw rose.
Available Functions:
Single Dummy: No door latch. Stationery door lever on one side of the door. Package Includes: 1 lever, 1 rose, and mounting screws.
Passage (Hall or Closet): For doors that don't need locking. Latch operates from either side of door. Package Includes: 2 levers, 2 roses, door latch, strike plate, dust box, faceplate, solid spindle, and mounting screws.
Privacy (Bedroom or Bathroom): For doors that could need privacy locking. Latch operates from either side. Push button on interior rose engages privacy; emergency release hole is on exterior rose. Turning inside lever will release privacy push button and retract the door latch. Package Includes: 2 levers, 2 roses, privacy button, door latch, strike plate, dust box, faceplate, slit spindle, and mounting screws
