Omnia 226S, Transatlantic Lever with Square Rose
A very sleek design, Omnia's 226S has a square rose with a retro-modern lever. The Transatlantic Leverset With Square Rose is made out of solid brass with non-rusting materials used throughout. The Transatlantic Lever with Square Rose is available in your choice of Satin Nickel, Polished Chrome, Satin Chrome, or Oil-Rubbed Bronze finishes. It will fit 1-3/8", 1-3/4", or 2" door thicknesses with 2-3/8" or 2-3/4" backsets.
Features of the Retro-modern Transatlantic Lever with Square Rose:
Solid brass construction.
Fits most standard door cut outs.
ADA Compliant
Specifications for the Omnia 226S Transatlantic Door Lever:
Material: Solid Brass
Lever Length: 5"
Lever Projection: 2-3/4"
Rose Length: 2-9/16" square
Door Thickness: 1-3/8", 1-3/4", or 2"
Backset: either 2-3/8" or 2-3/4"
28 degrees rotation to retract latch.
Fits standard 2-1/8" inch door bore.
Concealed screw rose.
Available Functions:
Single Dummy: No door latch. Stationary door lever on one side of the door. Package Includes: 1 lever, 1 rose, and mounting screws.
Passage (Hall or Closet): For doors that don't need locking. Latch operates from either side of door. Package Includes: 2 levers, 2 roses, door latch, strike plate, dust box, faceplate, solid spindle, and mounting screws.
Privacy (Bedroom or Bathroom): For doors that could need privacy locking. Latch operates from either side. Push button on interior rose engages privacy; emergency release hole is on exterior rose. Turning inside lever will release privacy push button and retract the door latch. Package Includes: 2 levers, 2 roses, privacy button, door latch, strike plate, dust box, faceplate, slit spindle, and mounting screws
