RCI 0161DDH Electric Strike

RCI 0161DDH Electric Strike

The 0161 is a 3/4" semi-mortise electric strike that is designed to operate with Pullman latch rim exit devices. The stainless-steel finish creates a sleek attractive architectural appearance. The slotted horizontal holes on the faceplate allow for easy and secure mounting during installation and correct alignment with the exit device. It features a hazard-free radius design.

• Energy: 200mA 12VAC/VDC Or 24VAC/VDC (Max at 12VDC)
• Strength: 1,500lbf Static 70ft-lb Dynamic
• Endurance: 500,000 Cycles
• Mode: Fail-Secure
• Dimensions: 1-3/4"W x 9"H x 1-5/8"D (45mm x 229mm x 41mm)
• Brushed Stainless Steel (32D) finish
• UL 1034 burglary-resistant Listed
• Endurance 500,000 cycles

Accessories
0161DDH - Double door housing, SPC finish (SPC=Silver Powder Coat)
​Note: UL 1034 Burglary-resistant listing does not apply with use of 0161DDH.

Applications
Commercial Centers
Industrial Buildings
Educational Facilities
Retail Outlets
Health Care Facilities
Office Complexe

RCI 0161DDH Electric Strike

The Double Door Housing is part of RCI

 0161DDH (0161 Series) or 0162DDH (0162 Series).

• Semi-mortise rim strike designed for use with Pullman latch rim exit devices
• Accommodates 1/2" to 3/4" (13mm–19mm) latch projection
• Ensures proper latch alignment with horizontal adjustment
• Stainless steel ensures superior strength and creates a sleek aesthetic design
• Lockdown holes for secure mount
• Non-handed
• 200mA 12VAC/VDC Or 24VAC/VDC (Max at 12VDC)
• 1,500lbf Static 70ft-lb Dynamic
• 500,000 Cycles
• Fail-Secure
