ABH A515 78-¾in to 83-⅛in Concealed Steel Hinge Guard Stop

ABH A515 78-¾in to 83-⅛in Concealed Steel Hinge Guard Stop

Full concealed heavy duty stainless steel pin and barrel continuous hinge with flush mount design and door edge guard on stop side providing targeted protection.

Technical Specifications
Material: Stainless steel pin and barrel
Load Capacity: 600 lbs. door weight maximum
Door Width: 48" maximum
Door Inset: No inset, flush mount
Standard Lengths: 78-3/4", 83-1/8", 85", 95", 118-3/4"
Fasteners: 10-24 x 3/4" undercut self-drilling stainless steel screws, #10 x 1-1/4" undercut wood screws stainless steel
Fire Rating: UL Listed for Fire Door Assemblies - 20 min (wood), 90 min (composite/hollow metal), 3 hr (hollow metal)
Weight: 13 lbs. average per unit
Edge Protection: Door edge guard on stop side only

Full concealed heavy duty with targeted edge protection on stop side.

ABH A515 78-¾in to 83-⅛in Full Concealed Hinge, No Inset, Door Edge Guard (Stop Side Only)

Key Features & Notables

• Edge Guard Stop Side
• Full Concealed Design
• Flush Mount Design
• 600 lb Load Capacity
• UL/ULC Listed for Use on Fire Door Assemblies
