Von Duprin 5547 Rim Device with various Trim Options
5547 Concealed vertical rod devices for use on single or double metal doors. UL listed for accident hazard installations and fits door stiles as narrow as 1 3/4" (44 mm). Specify for 2 1/4" door. Standard device fits 6' 8" to 8'0" door height.
5547-F Fire exit concealed vertical rod devices for use on 8' x 8' (2438 mm x 2438 mm) double metal doors swinging the same direction or double egress. UL listed for up to 3 hour labeled installations and fits door stiles as narrow as 4 3/4" (121 mm). Standard device fits 6'8" to 8'0" door height. Double doors swinging same direction using a pair of 5547-F devices must not have an overlapping astragal.
5547WDC-F Fire exit concealed vertical rod devices for use on 8' x 9'3" (2438 mm x 2819 mm) double wood doors swinging same direction or double egress. UL listed for up to 90 minute doors and fits stiles as narrow as 4 3/4" (121 mm). Standard device fits 6'8" to 8'0" door height. Double doors swinging same direction using a pair of 5547WDC-F devices must not have an overlapping astragal. Device is field reversible.
5547WDC Concealed vertical rod devices for use on single or double wood doors. Fits door stiles as narrow as 4" (102 mm).
